Metro DI for KMP mobile: From God Objects and manually checked Singletons to Compile-Time Injection

The Starting Point: God Object, Custom Singletons, and Lazy Maps

In the previous article i talked about how the Ktor backend replaced a God Object BackendComponent with Metro’s compile-time graph. The mobile side of Rudio had a remarkably similar story, except it was more interesting because there were actually two God Objects working together and someone (looks in the code, realizes it was me) had written a custom thread-safe singleton.

The centerpiece was ApplicationComponent (this should give you flashbacks if you’ve ever written manual DI or something similar in a KMP project):

object ApplicationComponent {

    private val appInitializer: MutableSet<AppInitializer> = mutableSetOf(
        NapierInitializer,
        FirebaseInitializer(),
        InAppReviewDataStoreCounterInitializer(),
        RevenueCatInitializer(),
        ObservabilityKeysInitializer(),
    )

    private var _coreComponent: CoreComponentImpl? = null
    val coreComponent: CoreComponent
        get() {
            return _coreComponent ?: error("CoreComponent not initialized")
        }

    fun initializeComponent() {
        _coreComponent = getSingleton { CoreComponentImpl() }
        appInitializer.forEach { it.initialize() }
    }

    @PublishedApi
    internal val singletons = mutableMapOf<KClass<*>, Any>()

    @PublishedApi
    internal val singletonFactories = mutableMapOf<KClass<*>, () -> Any>()

    inline fun <reified T : Any> registerSingleton(noinline factory: () -> T) { ... }
    inline fun <reified T : Any> getSingleton(): T { ... }
}

val coreComponent get() = ApplicationComponent.coreComponent

Version 1.0.X shipped with this approach, only from 1.1.X is when Metro landed, no crashes whatsoever regarding any of the DI, it works… but at a mental cost if you ask me.

There was a global coreComponent property holding singletons so every ViewModel could do = coreComponent.navigatorDispatcher in its constructor defaults. Convenient, until you wonder what coreComponent means in a test that never called initializeComponent().

CoreComponent was an interface listing everything the app might ever need:

interface CoreComponent : CoroutinesComponent, DatabaseComponent {
    val json: Json
    val dataStore: DataStore<Preferences>
    val httpClient: HttpClient
    val navigatorDispatcher: NavigatorDispatcher
    val navigatorDirections: NavigatorDirections
    val invalidAuthenticationStateStore: InvalidAuthenticationStateStore
    val snackStateStore: SnackStateStore
    val toastManager: ToastManager
    val locationRepository: LocationRepository
    val appleSignIn: AppleSignIn
    val googleSignIn: GoogleSignIn
    val permissionHandler: PermissionHandler
    val analyticsTraces: AnalyticsTraces
    val analyticsRepository: AnalyticsRepository
    val adsRepository: AdsRepository
    val purchasesRepository: PurchasesRepository
    val userInMemoryCache: UserInMemoryCache
}

And CoreComponentImpl brought that interface to life with 18+ lazy properties:

internal class CoreComponentImpl(
    private val coroutinesComponent: CoroutinesComponent = CoroutinesComponentImpl.create()
) : CoreComponent, CoroutinesComponent by coroutinesComponent {

    init {
        SingletonImageLoader.setSafe { context -> ImageLoader.Builder(context)... }
    }

    override val json: Json by lazy { getSingleton { commonJsonSerialization() } }
    override val toastManager: ToastManager by lazy { getSingleton { ToastManagerImpl(applicationScope) } }
    override val locationRepository: LocationRepository by lazy { getSingleton { createPlatformLocationRepository() } }
    // ... 15 more of these
}

Then there was CoroutinesComponentImpl:

internal class CoroutinesComponentImpl : CoroutinesComponent {
    companion object {
        fun create(): CoroutinesComponent = getSingleton(::CoroutinesComponentImpl)
    }

    override val mainImmediateDispatcher = Dispatchers.Main.immediate
    override val mainDispatcher = Dispatchers.Main
    override val ioDispatcher = Dispatchers.IO
    override val defaultDispatcher = Dispatchers.Default
    override val applicationScope: CoroutineScope = CoroutineScope(SupervisorJob() + mainImmediateDispatcher)
}

And finally, there was SingletonCheck, adapted from Dagger’s SingleCheck.java and ported to KMP (my code was probably an older commit in Dagger’s code so changes might be possible) with SynchronizedObject instead of the Java lock:

class SingletonCheck<T : Any>(private val factory: () -> T) {
    @Volatile private var instance: T? = null
    private val lock = SynchronizedObject()
    private var creating = false

    fun get(): T {
        return instance ?: synchronized(lock) {
            instance ?: run {
                if (creating) error("Reentrant singleton creation detected")
                creating = true
                factory().also {
                    instance = it
                    creating = false
                }
            }
        }
    }
}

fun <T : Any> getSingleton(obj: () -> T) = SingletonCheck(obj).get()

It’s also completely unnecessary when a compile-time DI graph handles object lifetimes for you. When you end up porting Dagger internals into your own project, well, it’s probably time to just use a real DI framework, so i did.

The KMP Dimension

The backend story was simple: one JVM target, one BackendGraph. The “mobile” side is three platforms (Android, iOS, and JVM desktop) and each one needs slightly different things at startup.

Android needs an Application reference to create a DataStore, open the SQLCipher database, and initialize Room. iOS initializes the graph without any platform type; all its platform bindings are contributed via @BindingContainer before the graph is created. Desktop is the same shape as iOS minus the mobile-specific SDKs.

This meant AppGraph couldn’t be a single interface with a single factory. It needed three flavors of the same contract.

AppGraph: Three Flavors of One Contract

The Android graph requires an Application to wire platform dependencies. Metro’s @DependencyGraph.Factory covers that:

// android/app/src/main/kotlin/.../di/AppGraph.kt
@DependencyGraph(AppScope::class)
@SingleIn(AppScope::class)
interface AppGraph : ViewModelGraph, MetroAppComponentProviders {
    override val metroViewModelFactory: MetroViewModelFactory
    val appInitializers: Set<AppInitializer>
    val navGraphRegistrars: Set<NavGraphRegistrar>

    @DependencyGraph.Factory
    fun interface Factory {
        fun create(@Provides application: Application): AppGraph
    }
}

ViewModelGraph is metrox’s marker interface that enables ViewModel multibinding. MetroAppComponentProviders is the Android-specific metrox hook that ties MetroViewModelFactory into the Activity’s ViewModelProvider. Metro generates the factory implementation at compile time.

The iOS graph has no factory. All platform bindings arrive via @ContributesTo @BindingContainer objects that Metro discovers automatically:

// composeApp/src/iosMain/kotlin/.../di/AppGraph.kt
@DependencyGraph(AppScope::class)
@SingleIn(AppScope::class)
interface AppGraph : ViewModelGraph {
    override val metroViewModelFactory: MetroViewModelFactory
    val navigatorDispatcher: NavigatorDispatcher
    val appInitializers: Set<AppInitializer>
    val navGraphRegistrars: Set<NavGraphRegistrar>
    val updateFcmTokenUseCase: UpdateFcmTokenUseCase
}

navigatorDispatcher and updateFcmTokenUseCase are listed directly because Swift code calls into the graph to wire navigation and push token updates. Android doesn’t need these exposed on the graph because it accesses them through the ViewModel layer.

AppScope is still just a class, same as the backend:

abstract class AppScope private constructor()

Nothing else. The private constructor means no accidental instantiation. Metro uses it as an aggregation marker to collect every @ContributesTo(AppScope::class) contribution into a single graph.

The entry points are straightforward. On Android:

class RudioApplication : Application(), MetroApplication {

    val appGraph: AppGraph by lazy {
        createGraphFactory<AppGraph.Factory>().create(this)
    }

    override val appComponentProviders: MetroAppComponentProviders
        get() = appGraph

    override fun onCreate() {
        super.onCreate()
        appGraph.appInitializers
            .sortedBy { it.order.order }
            .forEach { it.initialize() }
    }
}

On iOS, MainViewController.kt exposes three Kotlin functions that Swift calls directly:

private val graph: AppGraph by lazy { createGraph<AppGraph>() }

fun initializeAppGraph() {
    graph.appInitializers
        .sortedBy { it.order.order }
        .forEach { it.initialize() }
}

fun updateFcmToken(token: String) {
    graph.updateFcmTokenUseCase.execute(token = token)
}

fun MainViewController(onAppInitialized: (() -> Unit)? = null): UIViewController {
    return ComposeUIViewController {
        App(
            viewModelFactory = graph.metroViewModelFactory,
            onAppInitialized = onAppInitialized,
        )
    }
}

Swift calls them in AppDelegate:

import RudioKt

class AppDelegate: NSObject, UIApplicationDelegate {

    func application(
        _ application: UIApplication,
        didFinishLaunchingWithOptions launchOptions: [UIApplication.LaunchOptionsKey: Any]? = nil
    ) -> Bool {
        MainViewControllerKt.initializeAppGraph()
        // ...
        return true
    }

    func messaging(_ messaging: Messaging, didReceiveRegistrationToken fcmToken: String?) {
        guard let token = fcmToken else { return }
        MainViewControllerKt.updateFcmToken(token: token)
    }
}

createGraph<AppGraph>() vs createGraphFactory<AppGraph.Factory>().create(this): same Metro API, two shapes, each appropriate to its platform.

@BindingContainer Across Platforms

The old CoreComponentImpl mixed everything together in one class: coroutines, serialization, networking, storage, platform services. With Metro, these split naturally by concern and by platform.

For the sake of simplicity i have another CoroutineBindings that provides the coroutine dependencies but the article is too long already, so i’ve merged them in the AppBindings.

AppBindings in commonMain provides everything that’s platform-independent:

@ContributesTo(AppScope::class)
@BindingContainer
object AppBindings {

    @Provides
    @SingleIn(AppScope::class)
    @ApplicationScope
    fun provideApplicationScope(
        @MainImmediateDispatcher mainImmediate: CoroutineDispatcher,
    ): CoroutineScope = CoroutineScope(SupervisorJob() + mainImmediate)

    @Provides
    @IoDispatcher
    fun provideIoDispatcher(): CoroutineDispatcher = Dispatchers.IO

    @Provides
    @DefaultDispatcher
    fun provideDefaultDispatcher(): CoroutineDispatcher = Dispatchers.Default

    @Provides
    @MainDispatcher
    fun provideMainDispatcher(): CoroutineDispatcher = Dispatchers.Main

    @Provides
    @MainImmediateDispatcher
    fun provideMainImmediateDispatcher(): CoroutineDispatcher = Dispatchers.Main.immediate

    @Provides
    @SingleIn(AppScope::class)
    fun provideJson(): Json = commonJsonSerialization() //which is the same one as backend's code

    @Provides
    @SingleIn(AppScope::class)
    fun provideHttpClient(
        json: Json,
        authRepository: Lazy<AuthRepository>,
        tokenRepository: TokenRepository,
    ): HttpClient = createHttpClient(json = json, ...)

    @Provides
    fun provideClock(): Clock = Clock.System
}

applicationScope is now a @SingleIn val-backed CoroutineScope. One instance, SupervisorJob scoped to the application lifetime, dispatcher taken through @MainImmediateDispatcher, pretty standard things nothing fancy.

Platform-specific things go in their own @BindingContainer. On Android, AppBindingsAndroid in androidMain provides the Application context, DataStore, and the SQLCipher-backed Room database you can check my other blog post on how i implemented sql cipher with some challenges in KMP when you pull in firebase and other dependencies that have lsqlite as transitive one:

@ContributesTo(AppScope::class)
@BindingContainer
object AppBindingsAndroid {

    @Provides
    @SingleIn(AppScope::class)
    @ApplicationContext
    fun provideApplicationContext(application: Application): Context = application.applicationContext

    @Provides
    @SingleIn(AppScope::class)
    fun provideDataStore(
        @ApplicationContext context: Context,
        @IoDispatcher ioDispatcher: CoroutineDispatcher,
        @ApplicationScope scope: CoroutineScope,
    ): DataStore<Preferences> = createDataStoreWithDefaults(context = context, ...)

    @Provides
    @SingleIn(AppScope::class)
    fun provideDatabase(
        @ApplicationContext context: Context,
        @ApplicationScope scope: CoroutineScope,
        @IoDispatcher ioDispatcher: CoroutineDispatcher,
    ): AppDatabase = Room.databaseBuilder(context, AppDatabase::class.java, dbFileName)
        .openHelperFactory(SupportOpenHelperFactory(...))
        .setDefaults()
        .build()
}

iOS and JVM have equivalent files with their platform-specific Room/DataStore variants. Each file is annotated @ContributesTo(AppScope::class). Metro merges all contributions automatically: no central list, no explicit @Module includes, no registration call.

Three Graphs, One Underlying Contract

AppGraph is declared three times: once in androidMain, once in iosMain, once in jvmMain (desktop). They look different on the surface. Android’s has a Factory that takes Application. iOS’s exposes navigatorDispatcher and updateFcmTokenUseCase because Swift interop needs to call into them directly. JVM’s is closer to the iOS shape.

Under the hood, Metro generates one implementation per platform and each one ends up with the exact same set of bindings. The reason: AppBindings in commonMain contributes dispatchers, Json, HttpClient, and Clock. AppBindingsAndroid / AppBindingsIos / AppBindingsJvm each contribute DataStore and AppDatabase using their platform’s storage API. Because all four files carry @ContributesTo(AppScope::class), Metro collects them all into the graph for that platform’s compilation target.

The graph interfaces differ because the entry point requirements differ. Android needs Application at graph creation time; iOS and JVM don’t. iOS Swift code needs to call a few things directly through the graph boundary; the other platforms don’t. But every ViewModel, every Repository, every UseCase compiled into that platform sees identical bindings: the same @IoDispatcher, the same HttpClient, the same AppDatabase. There’s no per-platform conditional logic in any of them.

Do We Even Need expect/actual?

Before the Metro migration, platform-specific behavior was often modeled as top-level expect fun. Several utilities in the codebase lived in shared/src/commonMain/kotlin/app/rudio/wifi/map/platform/ as bare expect functions:

// shared/src/commonMain - the old pattern
expect fun deviceModel(): String
expect fun osVersion(): String
expect fun appVersion(): String

Each platform provided the matching actual fun. It compiled. It ran. But the moment you tried to test a ViewModel that called deviceModel() in commonTest, you hit a wall: the function is a concrete expect declaration. There is no interface to swap out. Writing a fake in commonTest would require providing an actual for every platform target in the test source set, and those actuals would need to call real platform APIs. Unit tests on the JVM can’t reach Android or iOS APIs. The fake cannot exist.

So i deleted all of those files and replaced them with interfaces:

// shared/src/commonMain - testable
interface DeviceInfoProvider {
    fun deviceId(): String
    fun deviceModel(): String
    fun osVersion(): String
    fun appVersion(): String
}

// shared/src/androidMain
@Inject
@ContributesBinding(AppScope::class)
class DeviceInfoProviderImpl(
    @ApplicationContext private val context: Context,
) : DeviceInfoProvider {
    // real implementation using PackageManager, Build, etc.
}

Now FakeDeviceInfoProvider lives in composeApp/src/commonTest and every test injects it directly:

class FakeDeviceInfoProvider(
    private val id: String = "test-device-id",
) : DeviceInfoProvider {
    override fun deviceId() = id
    override fun deviceModel() = "test"
    override fun osVersion() = "test"
    override fun appVersion() = "1.0"
}

The @ContributesBinding(AppScope::class) on the platform class tells Metro to bind DeviceInfoProviderImpl as DeviceInfoProvider. Every ViewModel receives the interface, never the platform class. The whole point: fakes can now exist in commonTest.

That said, expect/actual is still the right tool for several categories:

Platform-specific Composable functions: @Composable fun GoogleMap(...), etc… Composables aren’t injected through the DI graph; they’re called from the Compose tree. expect fun is the only mechanism that lets commonMain declare a Composable that has a platform-specific implementation.

Wrapping a platform SDK class: expect class AdmobAdsManager, expect class AdsConsentManager, expect class DatabaseKeyManager. When the platform SDK class is the implementation (Google’s AdMob SDK on Android, a no-op stub on other targets), the expect/actual wrapping is the right layer. The trick is to then put a testable interface (AdsManager, ConsentManager) in front of it so the expect class itself doesn’t leak into ViewModel constructors, you can inject these too later on as well.

Scaffolding required by libraries: expect object AppDatabaseConstructor : RoomDatabaseConstructor<AppDatabase>. Room’s KMP code generation requires this pattern. It’s not a design choice; it’s what the library demands.

Simple platform values: expect val currentPlatform: Platform. When it’s just a value with no methods, no lifecycle, no state, expect val is the simplest correct tool.

The rule of thumb: if something needs a Fake in commonTest, model it as an interface and bind the platform implementation via @ContributesBinding. If it wraps a platform SDK that only exists on one target and tests don’t need it, expect/actual is fine.

Testing With Fakes

The whole point of converting expect fun to interface + @ContributesBinding is this: in tests you never touch the DI graph at all.

Each integration test lives in composeApp/src/commonTest and constructs the ViewModel directly through its constructor, passing fakes instead of real implementations. No ApplicationComponent.initializeComponent(), no graph creation, no mocking framework:

@OptIn(ExperimentalTestApi::class, ExperimentalCoroutinesApi::class)
class SignUpIntegrationTest {

    @BeforeTest
    fun setUpMainDispatcher() {
        Dispatchers.setMain(UnconfinedTestDispatcher())
    }

    @AfterTest
    fun tearDownMainDispatcher() {
        Dispatchers.resetMain()
    }

    @Test
    fun createAccountButton_isDisabledWithoutInput() = runComposeUiTest {
        val viewModel = signUpViewModel()
        renderScreen(viewModel)
        createAccountButton().assertIsNotEnabled()
    }

    @Test
    fun signUp_navigatesToCheckEmail_onSuccess() = runComposeUiTest {
        val nav = FakeNavigatorDispatcher()
        val authRepository = FakeAuthRepository(
            signUpResult = SignUpResult.Success(user = verifiedUser, tokens = tokens),
        )
        val viewModel = signUpViewModel(nav = nav, authRepository = authRepository)
        renderScreen(viewModel)
        fillForm()
        createAccountButton().performClick()

        assertEquals(1, nav.navigateSingleTopCalls.size)
        assertTrue(nav.navigateSingleTopCalls.first() is CheckYourEmailGraph.CheckYourEmailScreen)
    }

    private fun signUpViewModel(
        nav: FakeNavigatorDispatcher = FakeNavigatorDispatcher(),
        authRepository: FakeAuthRepository = FakeAuthRepository(),
        passwordCredentials: FakePasswordCredentials = FakePasswordCredentials(),
        // ...
    ): SignUpViewModel = SignUpViewModel(
        navigatorDispatcher = nav,
        authRepository = authRepository,
        passwordCredentialManager = passwordCredentials,
        // ...
    )

    private fun ComposeUiTest.createAccountButton(): SemanticsNodeInteraction {
        val createAccount = runBlockingGetString(Res.string.create_account)
        return onNode(hasText(createAccount) and hasClickAction())
    }
}

FakeAuthRepository has a configurable result and records every call. The default is a failure case so most tests don’t need to configure anything:

class FakeAuthRepository(
    private val signUpResult: SignUpResult = SignUpResult.Failure.EmailAlreadyRegistered,
    // ...
) : AuthRepository {

    val signUpCalls = mutableListOf<SignUpInvocation>()

    override suspend fun signUp(
        email: String,
        username: String,
        password: String,
    ): SignUpResult {
        signUpCalls += SignUpInvocation(email, username, password)
        return signUpResult
    }
}

A test that needs success overrides only the result it cares about. A test that needs to assert the repository received specific arguments checks authRepository.signUpCalls. Nothing else changes.

Shared fakes live in composeApp/src/commonTest/kotlin/.../fakes/. One fake per interface, named Fake<InterfaceName>. They’re shared across test classes: FakeNavigatorDispatcher, FakeAuthRepository, FakeDeviceInfoProvider, FakeToastManager, and about 30 others. A new test needs two things: a private fun viewModel(...) helper that wires fakes with sensible defaults, and the actual test methods. That’s it.

ViewModels: From companion fun factory() to @Inject

The old ViewModel pattern was constructor defaults pointing at coreComponent.* and a companion factory() function that callers had to know about:

// before
class SignInViewModel(
    savedStateHandle: SavedStateHandle,
    private val navigatorDispatcher: NavigatorDispatcher = coreComponent.navigatorDispatcher,
    private val signInWithEmailUseCase: SignInWithEmailUseCase = SignInWithEmailUseCase.create(),
    private val passwordCredentialManager: PasswordCredentials = PasswordCredentials.create(),
    private val socialSignInPresenter: SocialSignInPresenter = SocialSignInPresenter(),
    private val toastManager: ToastManager = coreComponent.toastManager,
) : ViewModel() {

    companion object {
        fun factory() = provideSavedStateFactory {
            SignInViewModel(savedStateHandle = it)
        }
    }
}

SignInWithEmailUseCase.create() might seem magical but create() was a companion object that called the constructor of SignInWithEmailUseCase which was private with default arguments so that we don’t expose dependencies that are with implementation in the creator module where they’ll need to be changed to api in for no reason, shitty guard but it worked.

And the call site:

// before
val viewModel = viewModel<SignInViewModel>(factory = SignInViewModel.factory())

Every ViewModel that needed SavedStateHandle followed this pattern. Every ViewModel that didn’t use SavedStateHandle used provideFactory instead of provideSavedStateFactory. These were custom helpers:

inline fun <reified T : ViewModel> provideFactory(crossinline creator: () -> T) =
    viewModelFactory { initializer { creator() } }

inline fun <reified T : ViewModel> provideSavedStateFactory(crossinline creator: (SavedStateHandle) -> T) =
    viewModelFactory { initializer { val ssh = createSavedStateHandle(); creator(ssh) } }

After Metro, the same ViewModel:

// after
@AssistedInject
@ViewModelKey
class SignInViewModel(
    private val navigatorDispatcher: NavigatorDispatcher,
    private val signInWithEmailUseCase: SignInWithEmailUseCase,
    private val passwordCredentialManager: PasswordCredentials,
    private val socialSignInPresenter: SocialSignInPresenter,
    private val toastManager: ToastManager,
    @Assisted private val savedStateHandle: SavedStateHandle,
) : ViewModel() {

    @AssistedFactory
    @ViewModelAssistedFactoryKey(SignInViewModel::class)
    @ContributesIntoMap(AppScope::class)
    fun interface Factory : ViewModelAssistedFactory {
        override fun create(extras: CreationExtras): SignInViewModel =
            create(extras.createSavedStateHandle())
        fun create(@Assisted savedStateHandle: SavedStateHandle): SignInViewModel
    }
}

@AssistedInject tells Metro that SavedStateHandle is provided externally at creation time, not through the graph. The nested Factory bridges Metro’s @AssistedFactory with metrox’s ViewModelAssistedFactory contract. @ContributesIntoMap(AppScope::class) auto-registers this factory into the Map<KClass<out ViewModel>, ViewModelAssistedFactory> that MetroViewModelFactory consults.

Similarly you can provide direct parameters, i still prefer passing a SavedStateHandle, just a preference…

ViewModels that don’t need SavedStateHandle are simpler, plain @Inject with @ContributesIntoMap:

@Inject
@ViewModelKey
@ContributesIntoMap(AppScope::class, binding = binding<ViewModel>())
class MainViewModel(
    private val navigatorDispatcher: NavigatorDispatcher,
    // ... other deps, no defaults, no coreComponent
) : ViewModel()

The call site becomes:

// after
val viewModel = metroViewModel<MainViewModel>()               // plain inject
val viewModel = assistedMetroViewModel<SignInViewModel>()     // assisted inject

provideFactory, provideSavedStateFactory, and every companion object { fun factory() } block across the entire codebase: deleted.

AppInitializer: Ordered Startup Without a God Object

The old startup was a hardcoded MutableSet inside ApplicationComponent:

// before - in ApplicationComponent
private val appInitializer: MutableSet<AppInitializer> = mutableSetOf(
    NapierInitializer,
    FirebaseInitializer(),
    InAppReviewDataStoreCounterInitializer(),
    RevenueCatInitializer(),
    ObservabilityKeysInitializer(),
)

fun initializeComponent() {
    _coreComponent = getSingleton { CoreComponentImpl() }
    appInitializer.forEach { it.initialize() }
}

Adding an initializer meant editing ApplicationComponent. The set is unordered: the iteration order of mutableSetOf follows insertion order, which is the declaration order in source code. If logging needs to come before Firebase, you’d better not reorder those lines.

After Metro, each initializer is self-registering and carries its own order:

interface AppInitializer {
    val order: AppInitializerOrder
    fun initialize()
}

enum class AppInitializerOrder(val order: Int) {
    LOGGING(order = 100),
    FIREBASE(order = 200),
    OBSERVABILITY_KEYS(order = 300),
    REVENUE_CAT(order = 400),
    DATA_STORE(order = 500),
}

Gaps between values are intentional: insert a new initializer between existing ones without renumbering anything.

NapierInitializer as a concrete example:

@Inject
@ContributesIntoSet(AppScope::class)
class NapierInitializer(
    private val crashlyticsAntilog: CrashlyticsAntilog,
) : AppInitializer {
    override val order: AppInitializerOrder = AppInitializerOrder.LOGGING

    override fun initialize() {
        if (BuildKonfig.isDebug) Napier.base(DebugAntilog())
        else Napier.base(crashlyticsAntilog)
    }
}

@ContributesIntoSet(AppScope::class) auto-registers it into Set<AppInitializer>. The startup loop on both Android and iOS:

appGraph.appInitializers
    .sortedBy { it.order.order }
    .forEach { it.initialize() }

FirebaseInitializer is expect/actual, platform-specific initialization, but the call site in the startup loop never has to care. Add a new initializer, pick an order value, done. ApplicationComponent doesn’t exist to be edited.

Self-Registering Nav Graphs

This is the before/after that the diff makes most viscerally clear. The old App.kt contained 35 explicit nav graph calls inside the NavHost block:

// before - in App.kt
NavHost(...) {
    onBoardingGraph()
    mapGraph()
    profileGraph()
    leaderBoardGraph()
    signInGraph()
    signUpGraph()
    forgotPasswordGraph()
    resetPasswordGraph()
    verifyEmailGraph()
    checkYourEmailGraph()
    disabledAccountGraph()
    settingsGraph()
    editProfileGraph()
    changePasswordGraph()
    changeEmailGraph()
    redeemPremiumCodeGraph()
    faqGraph()
    publicUserProfileGraph()
    userPoisGraph()
    poiDetailsGraph()
    cityOrCountrySearchGraph()
    reportPoiGraph()
    speedTestGraph()
    speedTestHistoryGraph()
    editHistoryGraph()
    verificationHistoryGraph()
    suggestEditSuccessGraph()
    xpRewardGraph()
    dailyXpClaimGraph()
    achievementsGraph()
    offlineRegionsGraph()
    offlineWifiListGraph()
    offlinePoiDetailsGraph()
    purchaseGraph()
    adNotLoadedGraph()
}

Each of these was a plain extension function on NavGraphBuilder defined inside its feature package and imported in App.kt. Adding a screen meant adding a function, adding an import, and adding a call in this block: three places to touch in a file that already had 35 of them.

After Metro, NavGraphRegistrar is a fun interface:

fun interface NavGraphRegistrar {
    fun NavGraphBuilder.register()
}

Each feature owns its own @Inject @ContributesIntoSet implementation. The old NavGraphBuilder.signInGraph() extension function becomes:

@Inject
@ContributesIntoSet(AppScope::class)
class SignInNavGraph(
    private val signIn: SignInContent,
) : NavGraphRegistrar {
    override fun NavGraphBuilder.register() {
        navigation<SignInGraph>(startDestination = SignInGraph.SignInScreen::class) {
            with(signIn) { register() }
        }
    }
}

fun interface NavContent {
    fun NavGraphBuilder.register()
}

@Inject
class SignInContent : NavContent {
    override fun NavGraphBuilder.register() {
        composable<SignInGraph.SignInScreen> { backStackEntry ->
            val viewModel = assistedMetroViewModel<SignInViewModel>()
            ...
            ...
            ...
        }
    }
}

SignInContent is an @Inject class that implements NavContent (the composable side). SignInNavGraph wires the navigation structure; SignInContent provides the composable. Metro constructs and injects both.

App.kt’s NavHost becomes:

// after
NavHost(...) {
    mainViewModel.navGraphRegistrars.forEach {
        with(it) { register() }
    }
}

Add a new screen: create the NavGraph class, annotate it, it’s registered. Delete a screen: delete its files, it’s gone. App.kt doesn’t change.

One important note: AppScope in @ContributesIntoSet must always import app.rudio.wifi.map.di.scope.AppScope. Accidentally importing dev.zacsweers.metro.AppScope (Metro’s own default) contributes to a different scope and Metro will report a Metro/MissingBinding error for Set<NavGraphRegistrar> at compile time. The error message is clear once you’ve seen it once; confusing if you haven’t, or you can use that default one as well, up to you.

ActivityGraph: A Child Scope for a Reason, a wrinkle in our set-up

Android has one more wrinkle: Activity-bound state. ViewModelScope gives you “lives as long as the ViewModel”, AppScope gives you “lives as long as the application”. But sometimes you need “lives as long as this specific Activity.

PlatformActivity is just a type alias to ComponentActivity and on iOS and JVM is just a stub.

That’s ActivityGraph:

@GraphExtension(ActivityScope::class)
interface ActivityGraph {
    val platformActivity: PlatformActivity

    @ContributesTo(AppScope::class)
    @GraphExtension.Factory
    fun interface Factory {
        fun createActivityGraph(@Provides platformActivity: PlatformActivity): ActivityGraph
    }
}

@GraphExtension(ActivityScope::class) declares a child graph scoped to ActivityScope. The nested Factory is annotated @ContributesTo(AppScope::class) so Metro auto-merges it into the parent AppGraph, no manual wiring in AppGraph itself. The Activity creates the child:

@ActivityKey
@ContributesIntoMap(AppScope::class, binding<Activity>())
@Inject
class MainActivity(
    private val metroViewModelFactory: MetroViewModelFactory,
    private val navigatorDispatcher: NavigatorDispatcher,
) : ComponentActivity() {

    lateinit var activityGraph: ActivityGraph
        private set

    override fun onCreate(savedInstanceState: Bundle?) {
        .... code
        super.onCreate(savedInstanceState)
        activityGraph = (application as RudioApplication).appGraph.createActivityGraph(this)
        if (savedInstanceState == null) {
            intent?.data?.toString()?.let { navigatorDispatcher.processDeepLink(deepLink = it) }
        }
        ... rest of the code
    }
}

The graph, and everything scoped @SingleIn(ActivityScope::class) inside it, is garbage-collected when the Activity instance is dead. ViewModels in AppScope cannot depend on ActivityGraph bindings, the scope hierarchy enforces this at compile time. A ViewModel that held a PlatformActivity reference would survive configuration changes and leak the old Activity. The scoping rules make that a compile error rather than a memory leak caught in a profiler session.

A concrete reason this scope exists: permission handling on Android requires a ComponentActivity to register ActivityResultLaunchers and check grant state. That’s an Activity-bound dependency, not an application-level one. Putting it in AppScope would mean holding a live Activity reference across configuration changes: instant memory leak. ActivityGraph is the right scope. The implementation is created with the Activity and destroyed with it, and Metro’s scope rules make it a compile error for any AppScope consumer to depend on it.

@SingleIn: Same Rule, Mobile Edition

The rule is identical to the backend: stateless classes are plain @Inject class. @SingleIn(AppScope::class) is opt-in, reserved for things that hold shared mutable state:

Add @SingleIn:

• NavigatorDispatcher (shared logic across the nav stack)
• ToastManager (shared custom toast logic and handler)
• UserInMemoryCache (shared in-memory cache)
• HttpClient (connection pool single instance)
• DataStore<Preferences> (file-backed, one instance)
• AppDatabase / Room (database connection, one instance)
• CoroutineScope (single SupervisorJob + MainImmediateDispatcher)

Leave as plain @Inject:

• Every Repository that only reads from injected HttpClient or database DAOs
• Every UseCase that only calls repositories
• Every Mapper that only transforms data types

The instinct to make everything a singleton to “be safe” is exactly what caused the old getSingleton { ... } call scattered across CoreComponentImpl. Metro makes the safe default correct: fresh instance unless you explicitly opt into shared lifetime, remember, not everything needs to be a singleton.

The Migration in One Commit

The mobile Metro adoption landed in a single commit. The diff touched roughly every feature’s ViewModel and nav file, removed the four God Object files (ApplicationComponent, CoreComponent, CoreComponentImpl, SingletonCheck), and dropped the ViewModelExtensions helpers. The net line count was negative, surprisingly.

What stayed exactly the same: every Repository, every UseCase, every Mapper, every domain model. Constructor injection was already the pattern; the only change was removing the default values that silently reached into coreComponent. The logic didn’t move. The wiring did and i am happy it did.

This is the DI setup powering Rudio - find free WiFi hotspots around you.

Stay hydrated and keep your scopes clean.
